OMS 7
Description
The OMS 7 optical sensor combines non-contact, optical with inertial measurement technology. This allows the simultaneous measurement of a wide range of variables such as vehicle speeds, slip, pitch and roll angles, accelerations and angular rates.
The optical speed measurement is characterized by its long-term stability and high accuracy. The high bandwidths of angular rate and acceleration sensors enable the detection of the smallest, highly dynamic changes in movement.
The fusion of optical speed measurement and movement data from angular rate and acceleration sensors enables the measurement of all necessary parameters with unprecedented accuracy and dynamics. In this way, the OMS 7 helps our customers to successfully perform their measurement tasks in an efficient and simple way.
Features
- Proven spatial filter principle
- Precise, low-noise sideslip angle
- Integrated angular rate and acceleration sensors
- Sensor fusion
- Highest dynamics due to 1kHz update rate
- CAN output
- Simple parameterization via Ethernet
- Long-life IR-LED lighting
- POI conversion
- Easy handling
- Precise optics / optomechanics
- Intelligent signal processing
Applications
- Longitudinal and lateral dynamics
- Tire and brake performance
- Indoor testing
- Motorsports
- Land survey
- ADAS testing
- Railroad
- Mobile machines
- Motorcylce
- Parking attempts
- Industrial applications
OMS 4
Description
The OMS 4 optical sensor combines non-contact, optical with inertial measurement technology.
The optical speed measurement is characterized by its long-term stability and high accuracy. The high bandwidths of angular rate and acceleration sensors enable the detection of the smallest, highly dynamic changes in movement.
The fusion of optical speed measurement and movement data from angular rate and acceleration sensors enables the measurement of all necessary longnitudinal parameters with unprecedented accuracy and dynamics. In this way, the OMS 4 helps our customers to successfully perform their longitudinal measurement tasks in an efficient and simple way.
Features
- Proven spatial filter principle
- Integrated angular rate and acceleration sensors
- Sensor fusion
- Highest dynamics due to 1kHz update rate
- CAN output
- Simple parameterization via Ethernet
- Long-life IR-LED lighting
- POI conversion
- Easy handling
- Precise optics / optomechanics
- Protection against undervoltage by UPS
Applications
- Longitudinal dynamics
- Brake measurement
- Tire performance
- Indoor testing
- Land Survey
- Rail Applications
- Mobile machines
- Motorcycle
- Industrial Applications
Software extension for brake & acceleration measurement
Description
The software extension for OMS 4 and OMS 7 sensors provides you with a powerful tool for carrying out brake and acceleration measurements. The extensive functions and output options enable you to record the measured values efficiently and precisely, whether as an extension for your existing data acquisition solution or as a stand-alone solution without additional data acquisition.
Features
- Direct calculation of characteristic values (e.g. MFDD, Dist, StartVel, …)
- Output to CAN bus / Ethernet
- Storage of measurements in a CSV file
- Various trigger options
- Automatic sequence control
- Sequence control via CAN commands possible
Towing Lug Mount T1
Description
The towing lug mount T1 enables easy and extremely stable mounting on the towing lug of vehicles. Due to its variable clamp, it can be installed on a wide variety of vehicle types. A centering pin makes assembly easier and prevents twisting. The double clamp allows variable adjustment along the towing lug mount. In addition, the double clamp is rotatably mounted and thus opens a multidimensional adjustment range. As a result, misalignments of the towing lug and the distance to the road can be corrected. The sensor can be ideally aligned on the vehicle without additional tools. Expandable and combinable with additional clamps, tubes, suction cups and magnets.
Side Mount S1
Description
The side mount S1 can be quickly and easily attached to any smooth surface using rubber suction cups. Due to its 3 beared support points, the mount also finds a secure hold on curved surfaces and thus ensures stable installation. Its double clamps enable variable adjustment along the support tubes as well as a multi-dimensional adjustment range. This allows a secure installation on complex vehicle surfaces. No additional tools are required to install the mount. The suction cups have a rubber surface. This avoids scratches and damage to the vehicle paintwork. Expandable and combinable with additional clamps, tubes, suction cups and magnets.
Side Mount M1
Description
The side mount M1 can be quickly and easily attached to any sheet steel surface using magnets. Due to its 3 beared support points, the mount also finds a secure hold on curved surfaces and thus ensures stable installation. Its double clamps enable variable adjustment along the support tubes as well as a multi-dimensional adjustment range. This enables secure installation on complex vehicle surfaces. No additional tools are required to install the mount. The magnets have a rubberized surface. This avoids scratches and damage to the vehicle paintwork. Expandable and combinable with additional clamps, tubes, magnets and suction cups.
